VHF: 136-174MHz UHF: 400-480MHz VHF-H: 136-174MHz UHF-H: 400-480MHz
512 channels and 33 zones
512 memory channels on the PT8200 enable the mobile to accommodate a vast number of users and groups. 33 zones on the PT8200 enable the user to group different channels as a group and provide flexibility in organizing workgroups. In addition, Each zone and channel can be assigned with a customized name for easy identification.
Rugged and Reliable Construction
It meets MIL-810-C/D/E/F standards. Vibration and extreme temperature, salt fog test, low pressure, solar radiation have been done on the radio, which assures your durable use in any harsh conditions.
Versatile Signaling built-in
Offering 2-Tone, 5-Tone, CTCSS and DTCS,MDC,KDC, DTMF as standard, offering flexibility and suitability for use is a variety of applications, including dispatch management.
Built-in 5W internal and 13W external speaker and employ Kirisun compander technology insure you hear clear, crisp voice even in a noisy environment.
Pins Auxiliary Port
Incorporating a 15-pin auxiliary port for developer usage, e.g. GPS, data transmission, ignition, back-to-back repeater, external emergency input, channel change and more.
6 programming keys allow you to customize your radio with a choice of OST, power level set, emergency, Squelch level set, scrambler, voice expander, Lone Worker, VOX level set, horn alert, talk-about and more.
Multiple emergency Mode
For enhanced user safety, lone work, a security check is designed on this radio. It requires the user to reset at a predetermined interval if not, the radio will automatically enter into emergency mode to ask help. During an emergency, ENI & background and emergency alarm could be sent to dispatch center and partners.
In the event of prolonged transmissions at high power and with temperature exceeding a preset limit, the radio will automatically switch to mid-power or low-power in order to avoid overheating. The maximum temperature level is a customer configurable parameter.
Enhanced Call Function
The enhanced call management functions include Emergency, PTT ID, call alert, radio check, kill/active, stun/revive, security verification, private call, group call, message, status, etc.
OST function allows users to set CTC/DCS by programming key in each channel.
Horn Alert Function
When receiving 5-Tone, 2-Tone, MDC, DTMF or KDC decode, the radio can be used to control vehicle functions such as the light or speaker etc. It can be used to alert the user to an incoming call, even when not in close proximity to the vehicle.
Scrambler feature provides enhanced security for your important public safety and private security communications.
The PT8200's GPS function, supported by control center and management software, allows users to be located instantly, either to dispatch among a group or locate an emergency call. Allowing for more efficient use of resources or determining location in life-threatening situations.
- VHF 136-174 MHz 25 watt
- UHF 400-470 MHz 25 watt
- VHF-H 136-174 MHz 45 watt
- UHF 400-470 MHz 40 watt
